Product details
Frame
| Frame | Alpha Gold Aluminium, tapered head tube, internal derailleur and dropper post routing, rack and kickstand mount, Boost141, 5 mm QR |
|---|---|
| *Fork | Size: XS SR Suntour XCM 32, coil spring, preload, lockout, 47 mm offset, Boost110, 15 mm thru axle, 100 mm travel |
| Size: S, M, M/L, L, XL, XXL SR Suntour XCM 32, coil spring, preload, lockout, 47 mm offset, Boost110, 15 mm thru axle, 120 mm travel |
|
| Max compatible fork travel | 120mm, XS: 100mm |
Wheels
| Hub front | Formula DC-511, 6-bolt, Boost110, 15 mm thru axle |
|---|---|
| Hub rear | Formula DC-2241, alloy, 6-bolt, Shimano 8/9/10 freehub, Boost141, 5 mm QR |
| Rim | Alex MD35, tubeless compatible, 32-hole, 35 mm width, Presta valve |
| Spokes | 14 g stainless steel |
| *Tyre | Size: XS, S, M, M/L, L, XL Bontrager XR3 Comp, wire bead, 30 tpi, 27.5x2.80" |
| Size: S, M, M/L, L, XL, XXL Kenda Havok, wire bead, 30 tpi, 27.5x2.80" |
|
| Rim strip | Bontrager TLR |
| Max tyre size | Frame: 27.5x2.80" or 29x2.40", Fork: See manufacturer |
Drivetrain
| Shifter | Shimano Deore M4100, 10 speed |
|---|---|
| Rear derailleur | Shimano Deore M5120, long cage |
| *Crank | Size: XS, S FSA Alpha Drive, 28T steel ring, Boost, 170 mm length |
| Size: M, M/L, L, XL, XXL FSA Alpha Drive, 28T steel ring, Boost, 175 mm length |
|
| Bottom bracket | Shimano 7420ST, 73 mm, threaded cartridge |
| Cassette | Shimano Deore M4100, 11-46, 10-speed |
| Chain | KMC X10, 10-speed |
| Pedal | VP-536 nylon platform |
| Max. chainring size | 1x: 32T |
Components
| Saddle | Bontrager Arvada, steel rails, 138 mm width |
|---|---|
| *Seatpost | Size: XS, S, M TranzX JD-YSP18, 100 mm travel, internal routing, 31.6 mm, 361 mm length |
| Size: M/L, L, XL, XXL TranzX JD-YSP18, 130mm travel, internal routing, 31.6 mm, 425 mm length |
|
| *Handlebar | Size: XS Bontrager alloy, 31.8 mm, 15 mm rise, 720 mm width |
| Size: S, M, M/L, L, XL, XXL Bontrager alloy, 31.8 mm, 15 mm rise, 750 mm width |
|
| Grips | Bontrager XR Trail Comp, nylon lock-on |
| *Stem | Size: XS, S, M Bontrager alloy, 31.8 mm, Blendr-compatible, 7-degree, 50 mm length |
| Size: M/L, L, XL, XXL Bontrager alloy, 31.8 mm, Blendr-compatible, 7-degree, 60 mm length |
|
| Head set | Semi-integrated, cartridge, 1-1/8" top, 1.5" bottom |
| Brake | Shimano MT200 hydraulic disc |
| *Brake rotor | Size: XS, S, M, M/L, L, XL, XXL Shimano RT26, 6-bolt,160 mm |
| Size: M, M/L, L, XL, XXL Shimano RT26, 6-bolt,180 mm |
|
| Brake Set | Shimano MT200 hydraulic disc |
Weight
| Weight | M - 15.88 kg / 35.01 lbs |
|---|---|
| Weight limit | This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb). |
