Product details
Specifications
*spec applies to all sizes unless otherwise noted
Frameset
| Frame | 300 Series Alpha Aluminium, Fazua Evation integrated drive system, tapered head tube, internal routing, flat-mount disc, mudguard mounts, 148x12 mm thru axle |
|---|---|
| Fork | Domane+ carbon, tapered alloy steerer, flat-mount disc, 12x100 mm thru axle |
| Frame fit | Endurance |
Wheels
| Wheel front | Bontrager Paradigm Comp 25, Tubeless Ready, 25 mm rim width, 100x12 mm thru axle |
|---|---|
| Wheel rear | Bontrager Paradigm Comp 25, Tubeless Ready, 25 mm rim width, Shimano 11/12-speed freehub, 148x12 thru axle |
| Skewer front | Bontrager Switch thru axle, removable lever |
| Max tyre size | 38c |
Drivetrain
| *Shifter | Size: 49, 52 Shimano 105 R7025, short-reach lever, 11-speed |
|---|---|
| Size: 54, 56, 58, 61 Shimano 105 R7020, 11-speed |
|
| Front derailleur | Shimano 105 R7000, braze-on |
| Rear derailleur | Shimano 105 R7000, long cage, 34T max cog |
| *Crank | Size: 49, 52 FSA Alloy for Fazua, 50/34 chain rings, 170 mm length |
| Size: 54, 56 FSA Alloy for Fazua, 50/34 chain rings, 172.5mm length |
|
| Size: 58, 61 FSA Alloy for Fazua, 50/34 chain rings, 175mm length |
|
| Cassette | Shimano 105 HG700-11, 11-34, 11-speed |
| Chain | Shimano 105 HG601, 11-speed |
Components
| Saddle | Bontrager Arvada Comp, steel rails, 138 mm width |
|---|---|
| Seatpost | Bontrager Comp, 6061 alloy, 27.2 mm, 8 mm offset, 330 mm length |
| *Handlebar | Size: 49, 52 Bontrager Comp VR-C, alloy, 31.8 mm, 100 mm reach, 124 mm drop, 40 cm width |
| Size: 54, 56 Bontrager Comp VR-C, alloy, 31.8 mm, 100 mm reach, 124 mm drop, 42 cm width |
|
| Size: 58, 61 Bontrager Comp VR-C, alloy, 31.8 mm, 100 mm reach, 124 mm drop, 44 cm width |
|
| Handlebar tape | Bontrager Supertack Perf tape |
| *Stem | Size: 49 Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 80 mm length |
| Size: 52, 54 Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 90 mm length |
|
| Size: 56, 58 Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 100 mm length |
|
| Size: 61 Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 110 mm length |
|
| Head set | FSA Integrated, sealed cartridge bearing, 1-1/8" top, 1.5" bottom |
| Brake | Shimano 105 hydraulic disc |
| *Brake rotor | Size: 49, 52, 54, 56, 58, 61 Shimano MT800, CenterLock, 160 mm |
| Size: 49, 52, 54, 56, 58, 61 Shimano EM810, CenterLock 160 mm |
Accessories
| *E-bike system | Size: 49, 52, 54, 56, 58, 61 Fazua Evation battery, 250 Wh |
|---|---|
| Size: 49, 52, 54, 56, 58, 61 Fazua Evation Drive Pack, 25 km/h (15.5 mph) max assist, 32 km/h for New Zealand |
|
| Size: 49, 52, 54, 56, 58, 61 Fazua Evation charger, 220-240V |
|
| Size: 49, 52, 54, 56, 58, 61 Fazua Evation touch remote |
Weight
| Weight | 56 - 15.21 kg/33.53 lb |
|---|---|
| Weight limit | This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 125 kg (275 lb). |
| Sizing | ||
|
Size-table |
||
| Size | Rider Height | Inseam |
| 44 | 150 - 153 cm | 71 - 73 cm |
| 4'11" - 5'0" | 28" - 29" | |
| 47 | 152 - 158 cm | 71 - 75 cm |
| 5'0" - 5'2" | 28" - 30" | |
| 50 | 158 - 163 cm | 74 - 77 cm |
| 5'2" - 5'4" | 29" - 30" | |
| 52 | 163 - 168 cm | 76 - 79 cm |
| 5'4" - 5'6" | 30" - 31" | |
| 54 | 168 - 174 cm | 78 - 82 cm |
| 5'6" - 5'9" | 31" - 32" | |
| 56 | 174 - 180 cm | 81 - 85 cm |
| 5'9" - 5'11" | 32" - 33" | |
| 58 | 180 - 185 cm | 84 - 87 cm |
| 5'11" - 6'1" | 33" - 34" | |
| 60 | 185 - 190 cm | 86 - 90 cm |
| 6'1" - 6'3" | 34" - 35" | |
| 62 | 190 - 195 cm | 89 - 92 cm |
| 6'3" - 6'5" | 35" - 36" | |
