Product details
| *Frame | Size: 48, 63 Trek butted chromoly disc touring, rack and mudguard mounts, 135x5 mm QR |
|---|---|
| Size: 51, 54, 57, 60 butted chromoly disc touring, rack and mudguard mounts, 135x5 mm QR |
|
| Fork | Alloy disc touring, rack mounts, 100x5 mm ThruSkew |
| Fender/rack mounts | Bontrager BackRack Deluxe, Interchange compatible, size small |
Wheels
| Hub front | Shimano M475, 6-bolt disc, 100x5 mm QR |
|---|---|
| Skewer front | 130x5 mm QR, ThruSkew |
| Hub rear | Shimano M475, 6-bolt disc, 135x5 mm QR |
| Rim | Bontrager Affinity Disc, Tubeless Ready, 36-hole, 21 mm width, Presta valve |
| Spokes | 14 g stainless steel |
| Tyre | Bontrager H1 Hard-case Ultimate, 700x38c w/reflective sidewall |
| Max tyre size | 29x2.00" |
Drivetrain
| *Shifter | Size: 48, 51, 54, 57, 60, 63 Shimano Sora R3000, 9-speed |
|---|---|
| Size: 48, 51, 54, 57, 60, 63 Shimano Sora R3030, 3-speed |
|
| Front derailleur | Shimano Sora R3030, 34.9 mm (w/28.6 adapter) clamp |
| Rear derailleur | Shimano Alivio M4000, long cage, 36T max cog |
| *Crank | Size: 48, 51 Shimano Alivio T4060, 48/36/26, 2-piece w/chain guard, 170 mm length |
| Size: 54, 57, 60, 63 Shimano Alivio T4060, 48/36/26, 2-piece w/chain guard, 175 mm length |
|
| Cassette | Shimano HG200, 11-36, 9 speed |
| Chain | KMC X9 |
| Pedal | Wellgo nylon body, alloy cage |
| Max. chainring size | 2x: 42T, 3x: 48T |
Components
| Saddle | Bontrager Evoke |
|---|---|
| *Seatpost | Size: 48 Bontrager alloy, 27.2 mm, 12 mm offset, 250 mm length |
| Size: 51, 54, 57, 60, 63 Bontrager alloy, 27.2 mm, 12 mm offset, 330 mm length |
|
| *Handlebar | Size: 48 Bontrager Comp VR-C, alloy, 31.8 mm, 100 mm reach, 124 mm drop, 40 cm width |
| Size: 51, 54 Bontrager Comp VR-C, alloy, 31.8 mm, 100 mm reach, 124 mm drop, 42 cm width |
|
| Size: 57, 60, 63 Bontrager Comp VR-C, alloy, 31.8 mm, 100 mm reach, 124 mm drop, 44 cm width |
|
| Handlebar tape | Bontrager Gel Cork tape |
| *Stem | Size: 48 Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 80 mm length |
| Size: 51 Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 90 mm length |
|
| Size: 54, 57 Bontrager Elite, 31.8 mm clamp, Blendr-compatible, 7-degree, 100 mm length |
|
| Size: 60, 63 Bontrager Elite, 31.8 mm clamp, Blendr-compatible, 7-degree, 110 mm length |
|
| Head set | 1-1/8" threadless, sealed cartridge bearings |
| Brake | TRP Spyre C 2.0 mechanical disc, 160 mm rotor |
Accessories
| *Cargo rack | Size: 48, 51, 54, 57, 60, 63 Bontrager BackRack Deluxe, Interchange compatible, maximum load 25 kg |
|---|---|
| Size: 48, 51, 54, 57, 60, 63 Bontrager Carry Forward |
Weight
| Weight | 54 - 14.24 kg / 31.4 lbs |
|---|---|
| Weight limit | This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 125 kg (275 lb). |
| Sizing | ||
|
Size-table |
||
| Size | Rider Height | Inseam |
| 44 | 150 - 153 cm | 71 - 73 cm |
| 4'11" - 5'0" | 28" - 29" | |
| 47 | 152 - 158 cm | 71 - 75 cm |
| 5'0" - 5'2" | 28" - 30" | |
| 50 | 158 - 163 cm | 74 - 77 cm |
| 5'2" - 5'4" | 29" - 30" | |
| 52 | 163 - 168 cm | 76 - 79 cm |
| 5'4" - 5'6" | 30" - 31" | |
| 54 | 168 - 174 cm | 78 - 82 cm |
| 5'6" - 5'9" | 31" - 32" | |
| 56 | 174 - 180 cm | 81 - 85 cm |
| 5'9" - 5'11" | 32" - 33" | |
| 58 | 180 - 185 cm | 84 - 87 cm |
| 5'11" - 6'1" | 33" - 34" | |
| 60 | 185 - 190 cm | 86 - 90 cm |
| 6'1" - 6'3" | 34" - 35" | |
| 62 | 190 - 195 cm | 89 - 92 cm |
| 6'3" - 6'5" | 35" - 36" | |
